CHRONOS RPF-4111High-speed bag palletizing robot

Available in

Canada & USA and Latin America

The RPF-4111, formerly AR-225, is one of the fastest robotic bag palletizing equipment available. Its superior stacking capabilities, optimized layout, and lower capital costs make it an excellent alternative to conventional palletizers.

The innovative robot gripper handles bags of various sizes with utmost care. It enables manufacturers of low-margin products to ship their goods without tears or damage.

Speed: up to 25 bags per minute

Applications: bags

360 Robotic Palletizer RPF-4111 360 image

Robotic palletizer view of palletizing unit

Robotic bag palletizer stacking bags on pallet

Robotic palletizing - gripper placing bag on a pallet

Robotic palletizing - pallet distributor

Features and benefits

Performant palletizing machine

The RPF-4111 robot palletizer increases uptime and throughput thanks to advanced technologies and high levels of automation. These answers various stacking needs while gently handling products.

Moreover, the robot’s speed matches our automated bagging machines, allowing facilities to optimize their complete packaging line.

Features

Performant and reliable FANUC robot
Independent and automatic pallet and sheet dispensers for maximum speed
Fast and seamless pallet changeovers using VFD technology
Precise bag positioning and overlapping for sturdier and standardized loads
Safely creates loads up to 96 inches high

Affordable alternative to conventional palletizers

The robot provides a cost-effective solution to today's demanding shipping and storing needs with its competitive production rates and prices.

Besides, the robotic cell’s design can be optimized to the manufacturers' floor space and requirements for more flexibility.

Features

Economical product infeed conveyor and load transfer conveyor
Durable and low-maintenance components

Intuitive and convenient operating system

The RPF-4111 comes with Premier Tech’s user-friendly and intuitive operating software named Pattern Expert. It automatically suggests optimal patterns according to the product size and pallet dimension. Operators can easily create patterns and edit existing ones with a few taps on the touchscreen.

Available in multiple languages, it is accessible remotely by Premier Tech whenever support is required.

Features

No programming skills or additional laptop required
Numerous layer configurations
Available in English, Spanish, and French

Get detailed specifications about this equipment

Download the brochure

How the RPF-4111 robotic palletizing solution works

The operator selects the pattern on the touchscreen.
An empty pallet is automatically dispensed and positioned to the stacking position on the conveyor. 
The robot’s end effector picks bags from the infeed conveyor and places them in their exact position on the pallet. 
When completed, the pallet load exits through the motorized conveyor. At the same time, a new pallet is dispensed to the stacking position.

Configurations

Additional options

The RPF-4111 can be equipped with various options to fit your specific palletizing requirements.

Automatic product changeovers for increased uptime
Automatic sheet dispenser for maximum speed
Leak and weight detectors coupled with a rejection conveyor to remove non-compliant bags
